Continuous palbox washer

The vat washer TE-2500 is part of the TE series, developed specifically to clean continuously containers, palbox, vats made of plastic or stainless steel and any element base pallet. Conceived to be fed automatically can integrate dumpers, turners, stackers and distackers, inlet and outlet buffers and any imaginable configuration to make the loading and unloading fully adapted to each need. At the same time, can be easily intergrated into existing automatic lines. Its production capacity, efficency and easy maintenance have been made TE the favorite series for those customers who are more exigent with hygiene and food safety.

Request a quote

Mimasa Technology

  • Hygienic Design

    Retention zones and 90º angles elimination, continuous welding, great accessibility. Let water flow!

  • Clean ad Aeternum

    The best filtering combination of the market, systems that allow safe interventions without stopping the line and solutions for the auto diagnostic.

  • Born to be Automated

    To facilitate the automatization of the sanitizing processes. Washing systems born to be automated.

  • The 10-Sides
    Technology

    Ten sides that need to be cleaned. Mimasa does not forget any of them.

Technical Features

  • Maximum clearence (WxH)

    1.000 x 1.200mm

  • Production

    100 u/h

  • Pumps power

    18,5 KW+ 18.5KW

  • Filtering

    Self-cleaning rotary filters

  • Stages

    Prewash-Wash-Rinse-Disinfection

  • Heating

    Steam or electrical (other options available)

  • Options and accessories
  • Adjustable top guiding system for different heights
  • Lateral guiding for different widths
  • Steam extractor systems
  • Detergent and disinfectant dosing systems
  • Conductivity control
  • Custom made solution for other elements washing
  • Recirculated rinse stage before the final rinse
  • HACCP register and control program
  • Blow-off between stages
  • Versiones calorifugadas

Can we help you to find what you need?

You will find the washing and drying system you need at Mimasa. Our technical team is at your disposal
to create together the ideal solution for your needs

Information request

Associated Machines

  • Your tailor-made project

    We design and manufacture tailor-made washing and sanitizing systems that are designed for each specific sector and companmy to fit their production needs.

    +

  • At your side

    Mimasa is by your side during the entire process. We help you choose the right solution for your application, we provide start-up and training, and we provide after sale parts and service. We are here when you need us most.

    +
